Description :
We have these machines in 500, 750, 1000 and 2000 liters per hourThis machine can
be used as
a complete shop setup for municipal water and most borehole water in South
Africa. The
machine consists of the following
-
Raw water pump to pump the water through the pre filters
-
Sand filter with Automatic Valve for backwashing. You can also use glass
media for better filtration if
you have high turbidity.
-
Carbon filter with Automatic Valve for backwashing. This removes chemicals,
taste and odours.
-
Antiscale Dosing System to protect the membranes from hardness in the water.
-
A big blue housing with a sediment filter to catch any particles that could
have passed.
-
High Pressure pump to pump the water through the membranes.
-
A choice of membranes based on your water quality
-
This machine requires 2 level float switches to switch the machine on an off
based on the water levels
in the raw and pure water tanks.
After this, the water should go into a stainless steel tank which you have
install a submersible UV to
prevent bacteria from growing.
Specification
-
Capacity: 6000 GPD
-
RO Membrane: 4 pcs
-
RO Pump: 3HP
-
Voltage/Hertz: 110V or 220V / 50Hz or 60Hz / Single-phase or
three-phase
-
Pipe Size: 3/4″ Feed, 1/2″ Permeate, 1/2″ Concentrate, 1/2″
Flush (BSP thread)
Features
-
Sediment Filter: 5 Micron Sediment Filter that removes sediments
and protects the system.
-
High-Pressure Pump: 1HP Motor Vertical Multi-Stage Pump with a
flow rate of 1080 Liters/H.
High-quality stainless steel Shimge Pump for long-life usage.
-
RO Membrane: One of the industry’s leading brackish water RO
elements – Vontron-4040.
-
Membrane Housing: 4″ x 40″ Stainless Steel Housing with 300PSI
maximum operating pressure.
-
Pressure Gauges: Glycerin Filled Gauges for monitoring the
system’s operating pressure and per liter
operating pressures.
-
Low-Pressure Switch: Safety device to protect the pump from
running dry when there is insufficient
water feed pressure.
-
Solenoid Valves: To assist with the on/off functionality of the
system and automatic membrane flush.
-
Flow Meters: One Product and One Waste Flow Meters – Enables the
operator to actually adjust the
product to waste ratio and monitor the system’s performance.
-
Regulator Valve: One Stainless Steel ANSI 316 Needle Valve –
regulates the product to waste ratio
(system’s recovery).
-
Micro-Computer Controller: A specialized controller designed by
Puritech for commercial systems with
automatic controls and TDS monitors.
Operating Parameters
-
180 PSI | Max. Feed TDS | 1000 ppm
-
Normal Salt Rejection: 99% | Max. Feed Hardness | 15 ppm
-
Minimum Salt Rejection: 96% | Feed pH Range | 3.0 – 10.0 ppm
-
Operating Temperature: 20 ̊C – 45 ̊C | Free Residual Chlorine |
0.1 ppm
-
Minimum Feed Pressure: 1.5Kg | Recovery Rate | 60% – 75%
